OnePlus Ace 5 Ultra Specifications

BASIC INFO
Brand	OnePlus
Model	Ace 5 Ultra
Status	Available
Release Date	2025, May 27
BODY
Dimensions	163.4 x 77 x 8.1 mm (6.43 x 3.03 x 0.32 in)
Weight	206 g (7.27 oz)
Colors	Blue, Black, Titanium
Body Material	–
SIMs	Nano-SIM + Nano-SIM
Water & Dust	IP65 dust tight and water resistant (low pressure water jets)
DISPLAY
Size	6.83 inches
Type	AMOLED, 1B colors, 144Hz, HDR10+, Dolby Vision, HDR Vivid, 800 nits (typ), 1400 nits (peak)
Resolutions	1272 x 2800 pixels, 20:9 ratio
PPI	450 ppi density
Multi-touch	Yes
Protection	Crystal Shield Glass
NETWORKS
2G	GSM 850 / 900 / 1800 / 1900 – SIM 1 & SIM 2
3G	HSDPA 850 / 900 / 1700(AWS) / 2100
4G	1, 3, 4, 5, 8, 18, 19, 26, 28, 34, 38, 39, 40, 41, 42, 48, 66
5G	1, 3, 5, 8, 28, 38, 40, 41, 48, 66, 77, 78 SA/NSA
Speed	HSPA, LTE-A (CA), 5G
GPRS	Yes
EDGE	Yes
CAMERA
Rear Triple	50 MP, f/1.8, 24mm (wide), 1/1.56″, 1.0µm, PDAF, OIS 8 MP, f/2.2, 16mm, 112˚ (ultrawide), 1/4.0″, 1.12µm
Features	LED flash, HDR, panorama
Videos	4K@30/60fps,1080p@30/60/120/240fps, gyro-EIS
Front	16 MP, f/2.4, 24mm (wide), 1/3″, 1.0µm HDR, Panorama 1080p@30fps, gyro-EIS
HARDWARE
YOU	Android 15, ColorOS 15
Chipset	Mediatek Dimensity 9400+ (3 nm)
CPU	Octa-core (1×3.73 GHz Cortex-X925 & 3×3.3 GHz Cortex-X4 & 4×2.4 GHz Cortex-A720)
GPU	Immortal-G925 MC12
RAM	12GB / 16GB
Storage	256GB / 512GB / 1TB
Card Slot	No
BATTERY
Type	Si/C Li-Ion
Capacity	6700 mAh
Removable	Non-Removable
Talk Time	N/A
Stand By	N/A
Charging	100W wired, PD, 100% in 39 min 7.5W reverse wired Bypass charging
Wireless Charging	No
COMMONS
Sound	Yes, with stereo speakers 3.5mm Jeck No
Sensors	Fingerprint (under display, optical), accelerometer, gyro, proximity, compass, color spectrum
Bluetooth	5.4, A2DP, LE, aptX HD, LHDC 5, BLE Audio
GPS	GPS (L1+L5), GLONASS (G1), BDS (B1I+B1c+B2a), GALILEO (E1+E5a), QZSS (L1+L5), NavIC (L5)
USB	USB Type-C 2.0
Wi-Fi	Wi-Fi 802.11 a/b/g/n/ac/6/7, dual-band
Infrared Port	Yes
NFC	Yes, HCE, eSE, NFC-SIM
