| Hardware Specifications |
| CPU |
Allwinner H616 Quad-core ARM Cortex-A53 processor |
| GPU |
G31-Supports OpenGL ES 1.0/2.0/3.2, Vulkan 1.1, OpenCL2.0 |
| SDRAM |
Memory capacity up to 4GB |
| FLASH |
32GB |
| BLUETOOTH |
bluetooth 5.0 |
| WiFi |
Built in 2.4G 5G WiFi Support IEEE 802.11 b/g/n/ac |
| LAN Ethernet |
10M/100M |
| Main Features |
| OS |
Android Q |
| Video decorder |
Supports video decoding up to 4k@60fps |
| Supports multi-formats: |
| H.265 Main10@L5.1 up to 4k@60fps,or 6K@30fps |
| VP9 Profile 2 up to 4k@60fps |
| AVS2 Jizhun 10bit Profile up to 4k@60fps |
| H.264 BP/MP/HP@L4.2 up to 4k@30fps |
| H.263 BP up to 1080p@60fps |
| MPEG-4 SP/ASP@L5 up to 1080p@60fps |
| MPEG-2 MP/HL up to 1080p@60fps |
| MPEG-1 MP/HL up to 1080p@60fps |
| Xvid up to 1080p@60fps |
| VP8 up to 1080p@60fps |
| Sorenson Spark up to 1080p@60fps |
| AVS/AVS+ Jizhujn Profile up to 1080p@60fps |
| WMV9/VC1 SP/MP/AP up to 1080p@60fps |
| JPEG HFIF file format up to 45MPPS |
| HDR |
supports 10-bit processing path for HDR video |
| supports SDR/HDR10/Hybird-log gamma EOTF and color space conversion |
| HDR10: compliant with CTA-861.3 and SMPTE ST 2048 |
| 3D Graphics |
Supports OpenGL ES 1.0/2.0/3.2, Vulkan 1.1, OpenCL2.0 |
| Decoder format |
H.265, AVI, H.264, VC-1, MPEG-2, MPEG-4, DIVD/DIVX, PMP, FLV, MP4, M4V, VOB, 3GP, MKV |
| Music format |
MP1, MP2, MP3, WMA, OGG, AAC, M4A, FLAC, APE, AMR, RA, WAV |
| Photo format |
JPEG/BMP/GIF/PNG/TIFF |
| Network Function |
Miracast, Airpla, Skype chatting, Picasa, Youtube, Primevideo, Flicker, Facebook, Online movies, etc. |
| Language |
Chinese, English, Germany , Japanese, Korea etc. 24 languages |
| OTA |
Support OTA update |
| Port Specifications |
| Port |
1 x HDTV 2.0 |
| 2 x High speed USB 2.0,support U DISK and USB HDD |
| 1 x TF CARD Support 1~32GB |
| 1 x 3.5 Phone out CVBS&L/R output |
| 1 x RJ45 LAN Ethernet 10M/100M |
| Power Supply |
DC 5V/2A |
| LED Indicator |
Power ON: blue; Standby: Red |
| Accessories |
| Accessories |
1 x Adapter |
| 1 x Gift Box |
| 1 x IR remote control |
| 1 x HDTV Cable |
| 1 x User Manual |
Mecool KH6 OTT Box
$50.99
