Hubsan ACE PRO+ GPS RC Drone

Hubsan ACE PRO+ GPS RC Drone

Brand: OPPO
Category: RC Drone

Offers

Our Rating

The overall rating is based on review by our experts

0

Specifications:

Aircraft

Dimensions Expand: 202.65×240.34×85.49mm
Folded: 199.24×129.4×85.49mm
Diagonal Wheelbase 274mm
Color Gray
Takeoff Weight (with battery) 560g
Hover Accuracy Indoor: Vertical ± 0.1m, Horizontal ± 0.1m

Outdoor: Height<7m,  Vertical < Height * 0.02m,

Horizontal < Height * 0.02m

Height>7m, Vertical ± 0.1m, Horizontal ± 0.5m

Max Ascension Speed 3m/s (N), 4m/s (S), 1m/s (F)
Max Descent Speed 1.5m/s (N), 3m/s (S), 1m/s (F)
Maximum Horizontal Flying Speed   (Windless at Sea Level) 12m/s (N), 16m/s (S), 1m/s (M)
Maximum Take-off Altitude          5000m
Max Wind Speed Resistance  Grade 8 Wind (16m/s)
Max Tilt Angle 30°(S), 20°(N), 20°(F)
Positioning GPS + GLONASS, Beidou Satellite
Flight Duration Hovering for 33 minutes

(Windless, measured in 2-4 meters hovering)                                      Slow Flight Time 37 minutes

(8m/s uniform flight)

Power System

Maximum Working Current 36A
Propeller Model: Foldable & Diameter 143mm
Color: Black
Motor Outward Rotation Brushless Motor
1503, KV2820
ESC Digital ESC Brushless 20A x 4

Camera

CMOS Image Sensor 1-inch CMOS Sensor

2.4um Large Pixel

Lens Specifications FOV 85°

Aperture f/2.8
EFL: 9.5mm

Distortion: <1.5%

Focus Point 3m to ∞
Maximum Video Encoding 4K@30fps
Shutter Speed 3-1/8000s
Video Resolution Shooting Video: 1080P@30fps

In Smart Mode: 1080P@30fps
Night Mode: 1080P@25fps

Video Bitrate 100Mbps-200Mbps
Photo Format JPEG
Video Format MP4 (H.265/HEVC)
Firmware Upgrade APP Online Upgrade
Supported SD Cards MicroSD Card, U3 or Class10

16G/32G/64G/128G

Wireless Transmission System

Image Transmission System SyncLeas 3
Effective Range FCC: 10KM
CE: <= 6KM; SRRC: <= 10KM
Band Mode Frequency Button
Transmission Delay Within 200ms
Antenna Position Forearm Support Foot
Band Mode Frequency Button
Remote Control HT018F

Gimbal

Gimbal HY817C
Stabilization 3-Axis (tilt, roll, pan)
Degree of Freedom Triaxial
Max Pitch Speed
120°/s
Mechanical Range Pitch: -120° to 45°
Roll: ± 35°
Yaw: ± 35°

Flight Controller

FC Version Third-generation Flight Controller
Basic Flight Mode Wind Resistance Mode / Sports Mode / Normal Mode / Movie Mode
Altitude Hold Mode Tof, Barometer
Fixed-point Visual Optical Flow, GPS
Unlock/Lock Outer “Eight” Unlock/Lock
Fill Light Support 0.5m-5m low light environment to automatically turn on the light
One Key Take-off/Landing APP Supported,Remote Control Unsupported
Headless Mode
Out of Control Protection
Low Battery Protection Automatically Return to Home and Land on Low Battery
Home Visual Recognition

(search for drone apron)

Visual Tracking Third-generation Tracking Technology (ATVT 3.0)
Waypoint Flight
Flying Around
Intelligent Battery Power Management, Overcurrent Protection,                                              Over-discharge Protection, Overcharge Protection,

Balanced Charging, Auto-Discharging Protection

ESC Self-developed ESC, digital PWM
Motor Stall Protection
Sensing System Forward Binocular Visual Perception,Precision Measurement Distance <12M

Fluctuate <0.5M, Perception Distance >15M

Backward Binocular Visual Perception,Precision Measurement Distance <12M

Fluctuate <0.5M, Perception Distance >15M

Downward Monocular Optical Flow, Tof Ranging

Effective Ranging Range 0.3-5M,Fluctuate <0.1M

Remote Control

Color Gray
Wireless Transmission Solution SyncLeas 3
Display Highlight LED Display
Working Temperature -5 Deg.C- 50 Deg.C
Effective Range FCC: 10KM
CE: 6KM; SRRC: 10KM
Built-In Battery 4400mAh
Mode Mode 2 (Left Hand Throttle)
Buzzer Support
Support Mobile System Android, iOS
Working Time 2.5h (Normal Flight Time)
Interfaces Type Lighting / Micro USB / Type-C

Battery

Battery Type Li-ion Battery 3S
Capacity 4500 mAh
Standard Voltage 11.4V
Charging Limit Voltage 13.05V
Discharge Rate 8C
Charging Time 90 minutes
Weight 245g
Working Temperature -5 Deg.C- 40 Deg.C
Charging Temperature 0 Deg.C- 40 Deg.C
Smart Battery Balance
Smart Battery
Smart Charging Head
Battery Smart Buckle
Automatic Discharge
Hibernation Mode

APP

APP Name X-Hubsan 2

Mobile Device

Requirements iOS 10.0 or higher
Android 6.0 Or higher
